HAND HELD GUN GRADE
Tack Free (TM 1014) IFE28-12 minutes 6-10 minutes
Cutting Time <45 minutes <30 minutes
Full Cure < 16 hours < 8 hours
Curing Pressure (TM 1009, moistened surfaces) <1.5kPa <1kPa
Post Expansion (TM 1010) <150% <80%
Density In Joint (3x10cm; WGM106) 21-25Kg/m3 15-19Kg/m3
Dimensional Stability (TM 1004) <2% <1%
Temperature Resistance of Cured Foam -50°C to +90oC -50°C to +90oC
Working Temperature (Can, application surfaces) +5°C to +35oC +5°C to +35oC
Tensile Strength/Elongation (TM 1018, dry surfaces >65kPa/ 13% >80kPa/ 13%
Tensile Strength/Elongation (TM 1018, moist surfaces >30kPa/ 8% >60kPa/ 22%
Compressive Strength (TM 1011 moistened surfaces) >10kPa >5kPa
Shear Strength (TM 1012 moistened surfaces) >35kPa >20kPa
Thermal Conductivity (EN12667, TM 1020) 0.033W/(m K) 0.033W/(m K)
Sound Reduction Index Rst,w (EN ISO 10140) 62dB 62dB
Water Vapour Permeability (EN 12086) <0.04 mg/(m h Pa) <0.06 mg/(m h Pa)
Foam Yield In Joint (3x5cm WGM107) 9M / can
Foam Yield (TM 1003) per 750ml can 37L 37L
Commodity Code 3214900000 3214900000

• The fresh foam adheres to most common building materials including wood, concrete, stone, plaster, metal, PVC and polystyrene.
• For fitting doors, windows and insulating pipes and filling gaps and can reduce the need for mechanical fixings.
• Areas of Application: Installation of window and door frames and entrance door linings (where a clean and controlled backfill is required) - filling of holes - insulation of penetrations - sealing of thermal and acoustic insulation boards - sealing and connection of joints - reducing the impact of thermal bridges

B3 Rating according to DIN 4102‐1.
